Double-walled reactor vessel with bottom discharge including accessories for the EasySyn reactor system.
Volume: 5000 l
Flange size: DN 150
Including stainless steel metal adapter M 16×1 (Male) to connect temperature hoses.
Scope of delivery:
Glasreactor incl. metal adapter
Technical Data
| Volume | 5 l |
| Fill level diameter ratio | 1.24 |
| Fill level at nominal volume | 165 mm |
| Vessel inner diameter | 205 mm |
| Vessel outer diameter | 250 mm |
| Height (room dimension) | 433 mm |
| Width (room dimension) | 303 mm |
| Depth (room dimension) | 250 mm |
| Flange type | acc. DIN 12214 with circular groove |
| Flange dimension | DN150 |
| Flange collar diameter | 159 mm |
| Bottom shape | Torispherical head |
| Bottom drain | yes |
| Bottom valve | Safety valve |
| Bottom drain outlet inner diameter | 10 mm |
| Bottom drain outlet outer diameter | 15 mm |
| Bottom drain outlet length | 65 mm |
| Bottom drain shape | straight |
| Tempering jacket filling capacity | 2.31 L |
| Tempering jacket inlet connection | DN 15 (tech-flange) |
| Tempering jacket inlet inner diameter | 15 mm |
| Vacuum application | yes |
| Tempering jacket outlet connection | DN 15 (tech-flange) |
| Tempering jacket oulet inner diameter | 15 mm |
| Thread closure system | M16x1 |
| Width across flats | WAF 22 |
| Material closure system | stainless steel 1.4404 |
| Reactor vessel material | borosilicate glass 3.3 DIN ISO 3585 |
| Working temperature | -50 – 230 °C |
| Useable volume | 1000 – 5800 ml |
| Useable volume with temperature probe min. | 1500 ml |
| Pressure max. | atmospheric pressure |
| Attainable vacuum | 3 mbar |
| Material in contact with medium | borosilicate glass 3.3 DIN ISO 3585, PTFE |
